Accompanying image by VT Coordinator Adam Gościniak shows Telewizja Polsat‘s 4K HDR IP OB truck.
Wednesday May 4th: Telewizja Polsat, one of Poland’s largest broadcast media companies, has chosen Leader reference signal generators and hybrid IP/SDI test and measurement instruments for a recently completed IP–based 4K HDR outside broadcast camera truck. The instruments were supplied by Leader channel partner 4Vision.
The 14 metre long vehicle conforms to the latest SMPTE ST 2059, SMPTE 2110, SMPTE 2022 and AMWA NMOS suite of standards, enabling interoperability with current and future systems thatTelewizja Polsat will create around this truck. It incorporates Leader’s latest technologies including an LT4610 IP/SDI video sync generator, LV5600 IP/SDI waveform monitors, an LV7600 rasterizer and an LT4448 emergency changeover unit. LV5600 waveform monitor displays have been integrated into the vision engineering positions plus the LV7600 rasterizer for the engineer in charge.
Leader’s LT4610 IP and SDI video sync generator will be used to generate traditional black-burst/tri-level sync and PTP reference. These signals remain locked together even if external GPS reference is lost. The LT4448 emergency changeover unit adds resilience for traditional SDI and audio references and the PTP best master clock algorithm.
“This new vehicle is a powerful and flexible production capability for capturing entertainment and sports events right up to HD-HDR and UHD-HDR,” says Pawel Fila, 4Vision’s Project Manager. “Leader’s LV5600 and LV7600 test instruments support Sony’s SR Live for HDR workflow and operational practices. They can analyse and display the SR Live metadata, allowing productions to ensure all HDR sources and SDR conversion products are correctly configured. The LV5600 and LV7600 can also display multiple HDR transfer characteristics with the waveform, vectorscope and picture.”
“An OB vehicle built on the basis of IP technology is for us, as one of the largest video content producers in Poland, an entry into a completely new area of production technology,” adds Jacek Sierpiński, responsible for the 4K HDR IP OB van project from Telewizja Polsat. “In this exciting challenge, we are glad to have a helping hand from the Leader company which has proved to be strongly committed to the development of IP technology along with its standards.”
“Being able to monitor IP and SDI within a single test and measurement environment is a big advantage,” adds Kevin Salvidge, Leader Europe’s Sales Engineering Manager. “Broadcast production teams have long experience with SDI–based test equipment. The LV5600 waveform monitor and LV7600 rasterizer can display IP and SDI video sources simultaneously. They provide the same monitoring and measurement resources irrespective of whether the video signal is IP or SDI. They also give engineering staff the tools they need to monitor and analyse IP network activity.”
The 4K HDR IP OB truck’s crew additionally have access to Leader’s CINEZONE which uses the color spectrum to represent luminance values. Luminance levels can be confirmed quickly without need for waveform representations. Levels over the adjustable maximum are displayed in white, highlights in red, mid-grays in green, shadows in blue and levels under the adjustable minimum in black. CINEZONE also reveals variations in luminance levels across dark areas.
Telewizja Polsat (www.polsat.pl) is the first and leading commercial broadcaster in Poland. With the best movies, TV series, music events, top-class talent shows as well as sport events, reliable and objective news, Polsat became the most-chosen TV station by millions of Polish viewers. Today, Polsat is a part of the leading media and telecommunications group – Grupa Polsat Plus that consists such companies as: Cyfrowy Polsat, Polkomtel, Telewizja Polsat, Netia and Grupa Interia. Due to the interesting programming offer, reaching more than 98% of household, Polsat is one of the most valued and recognizable brands in Poland. The strongest pillars of the station are: great entertainment, fascinating movies, reliable and fast news and exciting sport events. Polsat is strongly investing in thematic channels development.
4Vision (www.4vision.pl) is a distributor of broadcast-quality film and television equipment from recognised global producers, and an integrator of television technology systems. Based in Poland, 4Vision provides complete AV and IP solutions including after-sale maintenance. A qualified team will help in the selection of optimal devices and accessories in line with the customer’s specific business profile.
Leader Electronics (www.leader.co.jp/en) has earned a worldwide reputation for designing and manufacturing highly reliable, practical, and powerful test & measurement instruments. Leader products are specified for broadcast, production, post-production, research, product development, and service applications. Manufacturing quality is built in every step of the way. The Leader product range includes award-winning 3G/HD/SD SDI waveform monitors and rasterizers, all with customizable layouts. Among the available options are 8K, 4K-UHD, CIE color chart, HDR measurement, test pattern generation, eye and jitter measurement, closed-caption display, IP, and 12G/6G-SDI. Leader has helped many customers manage their transition from analog to digital, from SD to HD, from HD to 4K/UHD, from SDR to HDR, and from BT.709 to BT.2020 wide color gamut. Leader also provides SMPTE ST2022-7 and ST2110 support for the transition from SDI to IP.
